CONSTRUCTION:
Thermoplastic polyurethane + Galvanized steel wire rope
FEATURE:
Anti-aging, water-repellent, anti-ultraviolet UVA, anti-ozone; working temperature -30℃+80℃ can withstand up to +110℃ in a short time; highly oil and grease resistant; resistant to most acid and alkali corrosion.
APPLICATION:
1.Widely used in mechanical matching of belt-type pressing and bonding interlining;
2.Bake a variety of foods, thawing frozen foods (rice, rice cakes, candy, etc.);
3.Various electronic components welding and conveying machinery are matched;
4.Conveyor belts with special conditions for industrial medicines, rubber and plastic sheets, electrical parts, heat treatment, heat resistance and non-adhesion;
5.Transportation with acids, alkalis, and corrosive materials.
Model | Step (mm) | Tooth (mm) | Thickness (mm) |
XL | 5.08 | 1.27 | 2.3 |
L | 9.525 | 1.91 | 3.6 |
H | 12.7 | 2.29 | 4.3 |
3M | 3 | 1.17 | 2.4 |
5M | 5 | 2.06 | 3.8 |
8M | 8 | 3.36 | 6 |
T5 | 5 | 1.2 | 2.2 |
T10 | 10 | 2.5 | 4.5 |
AT5 | 5 | 1.2 | 2.7 |
AT10 | 10 | 2.5 | 5 |
